4-20mA to 2-10V Conversion Shunt Resistor Guide

Converting from 4-20mA to 2-10V is a Standard way to convert the 4-20mA output signal into a voltage output .

To covert 4-20mA to 2-10V  resistor known as a shunt resistor is placed into the circuit. using ohms law this shunt resistor converters the 4-20mA into a Voltage output

How is the 4-20mA shunt resistor calculated for 2-10V?

using ohms law the R=V/I the required resistor can be calculated as shown in the image below

Where is the 4-20mA to 2-10V shunt resistor fitted?

The circuit diagram below demonstrates where to place the 500R shunt resistor
