The OSL 4-20mA Pressure sensor is manufactured in the UK and has short lead time of 1 week

✔ UK-made industrial pressure sensor
✔ 4–20 mA current loop output (2-wire)
✔ Pressure ranges from 0.5 Bar to 700 Bar
✔ High accuracy options up to ±0.10% BFSL
✔ Gauge or absolute pressure versions available
✔ Durable ceramic sensing element
✔ Wide operating temperature range
✔ Customisable ports, pressure ranges & connectors

This is an established product that uses the 4-20mA current loop to represent pressure.

OSP-A 4-20mA Pressure sensor Specifications

• Pressure ranges from 0.5 to 700 Bar
• Accuracy choice from ±0.25 to ±0.10% NLH ( BFSL)
• Gauge or Absolute
• Media Temperature -40 °C to +125 °C
• Ceramic sensor for corrosive resistance

OSP-A 4-20mA Description

The 4-20mA pressure sensor has 2 wires for power and signal. The supply is attached to the positive and negative terminal and a current meter is placed in between the -Ve connection from the Pressure sensor to the -Ve of the supply . the current drawn from the sensor will then correlate to the pressure.

4-20mA Pressure sensor Customisation and Design

What sets OnlineSensors Ltd apart from other instrumentation companies is that we are open to work with our customers to customise to their requirements , an example of what we can modify is below.

• Pressure ports
• Housing and enclosures
• Pressure Range
• Output connections

The above are just some examples , the best advice is to get in touch with us
