The Yocto-MaxiThermistor is a USB interface for NTC and PTC thermistors, it converts 6 thermistors into a USB interface.

It can measure  up to six temperature sensors. Each of the six channels can be configured independently thanks to tables or reference temperatures and β coefficients.

The Yocto-MaxiThermistor is an isolated device: there is an electric isolation between the sensor part and the USB part.

Yocto-MaxiThermistor is shipped with six tiny NTC thermistors connected to a 10 cm wire. You can extend them with any regular electric wire.

The six channel terminal block allows the use of 30-18 AWG wire. If you need to use bigger wire, choose the Yocto-Thermistor-C.


The Yocto-MaxiThermistor can also be used as a multichannel ohm-meter.

This device can be connected directly to an Ethernet network using a YoctoHub-Ethernet, to a WiFi network using a YoctoHub-Wireless-n and to a GSM network using a YoctoHub-GSM.

Product Overview

  • Product Name: Yocto-MaxiThermistor
  • Product ID: THRMSTR2
  • Hardware Release: Rev. B
  • Country of Manufacture: Switzerland

Technical Specifications

  • Channels: 6
  • Refresh Rate: 1Hz
  • Measuring Range: 100Ω to 500KΩ
  • Accuracy (1KΩ to 10KΩ): ~0.1%
  • Typical Accuracy: ~1%
  • Protection Class: IEC 61140 Class III
  • USB Isolation (Dielectric Strength): 1.5kV
  • RoHS Compliance: RoHS III (2011/65/UE + 2015/863

Operational Specifications

  • Normal Operating Temperature: 5°C to 40°C
  • Extended Operating Temperature: -30°C to 85°C

Software and Integration

  • Driver: Driverless (No driver needed)
  • Supported Operating Systems:
    • Windows (PC & IoT)
    • Linux (Intel & ARM)
    • macOS
    • Android
  • Supported SDKs / Libraries:
  • Local API: C++, Objective-C, C#, VB.NET, UWP, Delphi, Python, Java, Android, LabVIEW
  • TCP-Only API: JavaScript, Node.js, PHP

Physical Characteristics

  • Dimensions: 58mm (W) x 50mm (L)
  • Weight: 14g
  • USB Connector: Micro-B
  • Suggested Enclosure: YoctoBox-MaxiIO-Transp

Yoctopuce

Yocto-Maxi Thermistor USB Thermistor Converter 6 Channel

£87.75

The Yocto-MaxiThermistor is a USB interface for NTC and PTC thermistors, it converts 6 thermistors into a USB interface.

It can measure  up to six temperature sensors. Each of the six channels can be configured independently thanks to tables or reference temperatures and β coefficients.

The Yocto-MaxiThermistor is an isolated device: there is an electric isolation between the sensor part and the USB part.

Yocto-MaxiThermistor is shipped with six tiny NTC thermistors connected to a 10 cm wire. You can extend them with any regular electric wire.

The six channel terminal block allows the use of 30-18 AWG wire. If you need to use bigger wire, choose the Yocto-Thermistor-C.


The Yocto-MaxiThermistor can also be used as a multichannel ohm-meter.

This device can be connected directly to an Ethernet network using a YoctoHub-Ethernet, to a WiFi network using a YoctoHub-Wireless-n and to a GSM network using a YoctoHub-GSM.

Product Overview

  • Product Name: Yocto-MaxiThermistor
  • Product ID: THRMSTR2
  • Hardware Release: Rev. B
  • Country of Manufacture: Switzerland

Technical Specifications

  • Channels: 6
  • Refresh Rate: 1Hz
  • Measuring Range: 100Ω to 500KΩ
  • Accuracy (1KΩ to 10KΩ): ~0.1%
  • Typical Accuracy: ~1%
  • Protection Class: IEC 61140 Class III
  • USB Isolation (Dielectric Strength): 1.5kV
  • RoHS Compliance: RoHS III (2011/65/UE + 2015/863

Operational Specifications

  • Normal Operating Temperature: 5°C to 40°C
  • Extended Operating Temperature: -30°C to 85°C

Software and Integration

  • Driver: Driverless (No driver needed)
  • Supported Operating Systems:
    • Windows (PC & IoT)
    • Linux (Intel & ARM)
    • macOS
    • Android
  • Supported SDKs / Libraries:
  • Local API: C++, Objective-C, C#, VB.NET, UWP, Delphi, Python, Java, Android, LabVIEW
  • TCP-Only API: JavaScript, Node.js, PHP

Physical Characteristics

  • Dimensions: 58mm (W) x 50mm (L)
  • Weight: 14g
  • USB Connector: Micro-B
  • Suggested Enclosure: YoctoBox-MaxiIO-Transp
£87.75
